NAS1003-15 Machine Bolt

Product Series: NAS
ECCN: EAR99
Schedule: 7318.15.8085

Price per Unit $5.20

Units per Pack 10

Price per Pack $52.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $52.00

Add item to quote

Head Style

Hexagon

Material

Iron alloy 660

Surface Treatment

Mil-s-5002 military specification single treatment response

Thread Class

Distance From Head Largest Bearing Surface To Shank Hole Center: 1.194 inches first hole and 1.214 inches first hole
Fastener Length: Between 1.404 inches and 1.434 inches
Features: Finished head
Features Provided: Finished head
Grip Length: Between 0.923 inches and 0.953 inches
Hardness Rating: 248.0 brinell standard and 341.0 brinell standard
Head Height: Between 0.109 inches and 0.141 inches
Material Specification: Ams 5735 assn standard 1st material response or ams 5737 assn standard 2nd material response or ams 5733 assn standard 3rd material response
Min. Tensile Strength (psi): 140000 pounds per square inch
Shank Unthreaded Hole Diameter: 0.070 inches first hole and 0.080 inches first hole
Specification Data: 80205-nas1003 professional/industrial association standard
Thread Diameter: 0.190 inches
Thread Direction: Right-hand
Thread Length: Between 0.451 inches and 0.511 inches
Thread Qty Per Inch (tpi): 32
Thread Series Designator: Unf (fine thread)
Width Between Flats: Between 0.367 inches and 0.376 inches
