NAS1097AD3-4 Solid Rivet

Product Series: NAS
ECCN: EAR99
Schedule: 7616.10.3000

Price per Unit $0.22

Units per Pack 100

Price per Pack $22.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $22.00

Add item to quote

Head Style

Undersized oval countersunk

Material

Aluminum alloy 2117

Surface Treatment

Mil-c-5541 military specification single treatment response

Countersink Angle: 100.0 degrees
Countersink Height: 0.021 inches
Fastener Length: 0.250 inches
Head Height: Between 0.003 inches and 0.005 inches
Head Major Diameter: Between 0.126 inches and 0.148 inches
Head Minor Diameter: Between 0.086 inches and 0.096 inches
Material Specification: Qq-a-430 federal specification single material response
Shank Diameter: 0.094 inches
Shank Style: Straight
Specification Data: 80205-nas1097 professional/industrial association standard
