NAS1097AD4-4.5 Solid Rivet
NAS1097AD4-4.5 Solid Rivet (2)
NAS1097AD4-4.5 Solid Rivet (3)
NAS1097AD4-4.5 Solid Rivet (4)
NAS1097AD4-4.5 Solid Rivet (5)
NAS1097AD4-4.5 Solid Rivet (6)
NAS1097AD4-4.5 Solid Rivet
NAS1097AD4-4.5 Solid Rivet (2)
NAS1097AD4-4.5 Solid Rivet (3)
NAS1097AD4-4.5 Solid Rivet (4)
NAS1097AD4-4.5 Solid Rivet (5)
NAS1097AD4-4.5 Solid Rivet (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1097AD4-4.5 Solid Rivet

Product Series
NAS
ECCN
EAR99
Schedule
7616.10.3000
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: LBS

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Undersized oval countersunk
Material
Aluminum alloy 2117
Surface Treatment
Mil-c-5541 class 1a. yellow military specification single treatment response
Countersink Angle
Between 70.0 degrees and 130.0 degrees
Countersink Height
Between 0.032 inches and 0.034 inches
End Application
H53
Fastener Length
0.281 inches
Head Height
Between 0.003 inches and 0.005 inches
Head Major Diameter
Between 0.188 inches and 0.196 inches
Head Minor Diameter
Between 0.134 inches and 0.144 inches
Part Name Assigned By Controlling Agency
Rivet
Shank Diameter
Between 0.124 inches and 0.127 inches
Shank Style
Straight w/radius chamfered tip
