NAS1097AD5-4 Solid Rivet

Product Series: NAS
ECCN: EAR99
Schedule: 7616.10.3000

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: LBS

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Head Style

Undersized oval countersunk

Material

Aluminum alloy 2117

Countersink Angle: 100.0 degrees
Countersink Height: 0.037 inches
Fastener Length: 0.250 inches
Head Height: 0.040 inches
Head Major Diameter: Between 0.225 inches and 0.247 inches
Head Minor Diameter: 0.190 inches
Material Specification: Qq-a-430 federal specification single material response
Shank Diameter: 0.156 inches
Shank Style: Straight
Specification Data: 80205-nas1097 professional/industrial association standard
