NAS1097KE5-4 Solid Rivet

Product Series
NAS
ECCN
EAR99
Schedule
7318.23.0000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Undersized oval countersunk
Material
Aluminum alloy 2219
Surface Treatment
Mil-c-5541 military specification single treatment response
Countersink Angle
100.0 degrees
Countersink Height
0.0372 inches
Fastener Length
Between 0.240 inches and 0.260 inches
Head Height
Between 0.003 inches and 0.005 inches
Head Major Diameter
Between 0.2251 inches and 0.2469 inches
Head Minor Diameter
Between 0.185 inches and 0.195 inches
Heat Treatment
T-81 solution heat treated
Shank Diameter
Between 0.155 inches and 0.158 inches
Shank Style
Straight
Specification Data
80205-nas1097 professional/industrial association standard
