NAS1102-06-8 Machine Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $0.49
Units per Pack 100
Price per Pack $49.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:
Total Packs 1
Total Price $49.00
Add item to quote
Head Style
Flat countersunk
Material
Steel
Surface Treatment
Qq-p-416 type 2 cl 3 federal specification all treatment responses
Thread Class
3a
Countersink Angle
Between 99.0 degrees and 101.0 degrees
Fastener Length
0.500 inches
Hardness Rating
Between 36.0 rockwell c and 40.0 rockwell c
Internal Drive Style
Torque set
Min. Tensile Strength (psi)
160000 pounds per square inch
Thread Diameter
0.138 inches
Thread Direction
Right-hand
Thread Length
Between 0.438 inches and 0.500 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unc (coarse thread)
Head Diameter
Between 0.231 inches and 0.279 inches
