NAS1149C0632R Flat Washer

NAS1149C0632R Flat Washer (2)

NAS1149C0632R Flat Washer (3)

NAS1149C0632R Flat Washer (4)

NAS1149C0632R Flat Washer (5)

NAS1149C0632R Flat Washer (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1149C0632R Flat Washer

Product Series: NAS
ECCN: EAR99
Schedule: 8112.29.0000

Price per Unit $0.37

Units per Pack 100

Price per Pack $37.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 100

Total Unit Quantity:

Total Packs 1

Total Price $37.00

Add item to quote

Material

Steel comp 301 or steel comp 302 or steel comp 304 or steel comp 316 or steel comp 321 or steel comp 347

Surface Treatment

Qq-p-35 federal specification single treatment response

Center Hole Shape: Round
Cross Sectional Shape: Rectangular
Edge Shape: Round
End Application: Mrap rg-33 auv
Material Specification: Mil-s-5059 military specification single material response or ams 5510 assn standard single material response or ams 5512 assn standard single material response
Overall Diameter: Between 0.620 inches and 0.645 inches
Specification Data: 80205-nas1149 professional/industrial association standard
Thickness: 0.032 inches
Hole Diameter: Between 0.380 inches and 0.400 inches
