NAS1149FN416B Flat Washer

Product Series: NAS
ECCN: EAR99
Schedule: 7318.22.0000

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Steel comp 1020 or steel comp 1025

Surface Treatment

Mil-dtl-13924 military specification single treatment response

Center Hole Shape: Round
Cross Sectional Shape: Rectangular
Edge Shape: Round
End Application: Cv-22
Material Specification: Ams 5046 assn standard single material response
Overall Diameter: Between 0.307 inches and 0.332 inches
Part Name Assigned By Controlling Agency: Flat washer
Thickness: Between 0.014 inches and 0.018 inches
Hole Diameter: Between 0.115 inches and 0.135 inches
