NAS1169C8L Finishing Washer

Product Series: NAS
ECCN: EAR99
Schedule: 8112.29.0000

Price per Unit $0.81

Units per Pack 50

Price per Pack $40.50

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 50

Total Unit Quantity:

Total Packs 1

Total Price $40.50

Add item to quote

Surface Treatment

Qq-p-35 federal specification single treatment response

Material Thickness: Between 0.014 inches and 0.018 inches
Min. Tensile Strength (psi): 160000 pounds per square inch
Outside Diameter: Between 0.557 inches and 0.582 inches
Overall Height: 0.087 inches
Recess Angle: Between 99.0 degrees and 103.0 degrees
Recess Diameter: Between 0.332 inches and 0.342 inches
Specification Data: 80205-nas1169 professional/industrial association standard
Style Designator: Finishing
Hole Diameter: Between 0.166 inches and 0.196 inches
