NAS1189E06P8 Socket Head Cap Screw

Product Series: NAS
ECCN: EAR99
Schedule: 7318.15.2091

Price per Unit $4.85

Units per Pack 10

Price per Pack $48.50

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $48.50

Add item to quote

Head Style

Flat countersunk

Material

Iron alloy 660 fastener

Surface Treatment

Qq-p-35 federal specification single treatment response fastener

Thread Class

Countersink Angle: Between 99.0 degrees and 101.0 degrees
Fastener Length: Between 0.469 inches and 0.500 inches
Hardness Rating: 24.0 rockwell c fastener and 35.0 rockwell c fastener
Internal Drive Style: Cross recess type 1
Locking Feature: Patch threads or pellet threads or strip threads
Material Specification: Ams5737 assn standard single material response fastener
Min. Tensile Strength (psi): 160000 pounds per square inch
Minimum Yield Strength: 85000 pounds per square inch
Specification Data: 80205-nas1189 professional/industrial association standard
Surface Finish: 32.0 microinches threads
Thread Diameter: 0.138 inches
Thread Direction: Right-hand
Thread Length: Between 0.350 inches and 0.443 inches
Thread Qty Per Inch (tpi): 32
Thread Series Designator: Unjc
Head Diameter: Between 0.231 inches and 0.279 inches
