NAS1190E04P6B Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $6.58
Units per Pack 10
Price per Pack $65.80
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:
Total Packs 1
Total Price $65.80
Add item to quote
Head Style
Pan
Material
Steel comp e4340 or steel comp 4140 or steel comp 8740 or steel comp 8735 or steel comp 6150
Surface Treatment
type 2 cl 2 federal specification single treatment response qq-p-416
Thread Class
3a
Fastener Length
Between 0.344 inches and 0.375 inches
Hardness Rating
36.0 rockwell c and 40.0 rockwell c
Head Height
Between 0.070 inches and 0.080 inches
Internal Drive Style
Cross recess type 1
Locking Feature
Patch threads
Min. Tensile Strength (psi)
160000 pounds per square inch
Specification Data
80205-nas1190 professional/industrial association standard
Surface Finish
32.0 microinches bearing surface of head
Thread Diameter
0.112 inches
Thread Direction
Right-hand
Thread Length
Between 0.294 inches and 0.375 inches
Thread Qty Per Inch (tpi)
40
Thread Series Designator
Unjc
Head Diameter
Between 0.205 inches and 0.219 inches
