NAS1198-5-6 Solid Rivet

Product Series
NAS
ECCN
EAR99
Schedule
7616.10.3000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Universal
Material
Iron alloy 660
Surface Treatment
Qq-p-35 federal specification single treatment response
Fastener Length
Between 0.365 inches and 0.385 inches
Head Height
Between 0.067 inches and 0.077 inches
Head Major Diameter
Between 0.296 inches and 0.328 inches
Heat Treatment
As fabricated
Material Specification
Ams 5737 assn standard single material response
Shank Diameter
Between 0.155 inches and 0.160 inches
Shank Style
Straight
Shear Strength
90000 single pounds per square inch
