NAS1200M5-6 Solid Rivet

Product Series: NAS
ECCN: EAR99
Schedule: 7318.23.0000

Price per Unit $134.37

Units per Pack 1

Price per Pack $134.37

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: LBS

Quantity will be increased in increments of 1

Total Unit Quantity:

Total Packs 1

Total Price $134.37

Add item to quote

Head Style

Flush (flat) countersunk

Material

Nickel alloy 400

Countersink Angle: Between 99.0 degrees and 101.0 degrees
Fastener Length: Between 0.928 inches and 0.948 inches
Head Major Diameter: 0.2469 inches
Heat Treatment: Annealed
Material Specification: Qq-n-281 federal specification single material response
Shank Diameter: Between 0.155 inches and 0.160 inches
Shank Style: Straight with radius chamfered tip
Shear Strength: 49000 single pounds per square inch
Specification Data: 80205-nas1200 professional/industrial association standard
