NAS1241AD5-4 Solid Rivet
NAS1241AD5-4 Solid Rivet (2)
NAS1241AD5-4 Solid Rivet (3)
NAS1241AD5-4 Solid Rivet (4)
NAS1241AD5-4 Solid Rivet (5)
NAS1241AD5-4 Solid Rivet (6)
NAS1241AD5-4 Solid Rivet
NAS1241AD5-4 Solid Rivet (2)
NAS1241AD5-4 Solid Rivet (3)
NAS1241AD5-4 Solid Rivet (4)
NAS1241AD5-4 Solid Rivet (5)
NAS1241AD5-4 Solid Rivet (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1241AD5-4 Solid Rivet

Product Series
NAS
ECCN
EAR99
Schedule
7318.23.0000
Price per Unit $106.03
Units per Pack 1
Price per Pack $106.03
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: LBS

Quantity will be increased in increments of 1

Total Unit Quantity:
Total Packs 1
Total Price $106.03
Add item to quote
Head Style
Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)
Material
Aluminum alloy 2117
Countersink Angle
Between 99.5 degrees and 100.5 degrees
Fastener Length
0.250 inches
Grip Length
0.141 inches
Head Major Diameter
Between 0.282 inches and 0.290 inches
Iii Part Name Assigned By Controlling Agency
Solid rivet- universal head
Shank Diameter
Between 0.171 inches and 0.175 inches
Shank Style
Straight w/radius chamfered tip
Special Features
Head is dimpled 0.020 max. depth x 0.030 max width
Specification Data
80205-nas1241ad5-4 professional/industrial association standard
