NAS1291C04M Self-Locking Extended Washer Nut

Product Series: NAS
ECCN: EAR99
Schedule: 8112.29.0000

Price per Unit $1.60

Units per Pack 25

Price per Pack $40.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:

Total Packs 1

Total Price $40.00

Add item to quote

Material

Stainless Steel

Thread Class

3b

Thread Series

Unc (coarse thread)

Thread Size

0.112 inches

Locking Feature: Prevailing torque all metal design
Nut Style: Hexagon
Overall Height: Between 0.103 inches and 0.125 inches
Tempurature Rating: 550.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 40
Washer Outside Diameter: 0.206 inches
Washer Thickness: 0.010 inches
Width Across Flats: Between 0.150 inches and 0.158 inches
Lubrication: Dry film lubricant
