NAS1301C10-8 Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.9000
Price per Unit $2.40
Units per Pack 20
Price per Pack $48.00
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 20

Total Unit Quantity:
Total Packs 1
Total Price $48.00
Add item to quote
Head Style
Pan
Material
Steel comp 301 secondary washer or steel comp 302 secondary washer or steel comp 304 secondary washer or steel comp 316 secondary washer or steel comp 347 secondary washer or steel comp 348 secondary washer
Thread Class
2a
Fastener Length
Between 0.468 inches and 0.500 inches
Head Height
Between 0.122 inches and 0.132 inches
Internal Drive Style
Cross recess type 1
Material Specification
Mil-s-7720 military specification 1st material response fastener or astm a582 assn standard 2nd material response fastener
Primary Washer Material Thickness
0.047 inches
Primary Washer Outside Diameter
0.337 inches
Primary Washer Style
Split helical ring
Secondary Washer Material Thickness
Between 0.029 inches and 0.035 inches
Secondary Washer Outside Diameter
Between 0.338 inches and 0.348 inches
Secondary Washer Relationship To Primary Washer
Not identical
Secondary Washer Style
Flat
Specification Data
80205-nas1301 professional/industrial association standard
Thread Diameter
0.190 inches
Thread Direction
Right-hand
Thread Length
Between 0.348 inches and 0.360 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unf (fine thread)
Washer Quantity
2
Head Diameter
Between 0.357 inches and 0.373 inches
