NAS1329A3K80 Plain Blind Rivet Nut

Product Series: NAS
ECCN: EAR99
Schedule: 7318.16.0085

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote

Head Style

Flat keyed

Material

Aluminum alloy 6053

Surface Treatment

Type 2 military specification single treatment response mil-a-8625

Thread Class

Thread Series

Unf (fine thread)

Thread Size

0.190 inches

Err Default: +0.010 to 0.080 inches
Head Height: 0.038 inches
Key Length: 0.061 inches
Material Specification: T 4 military specification all material responses gr e mil-r-1150
Nut Diameter: Between 0.246 inches and 0.250 inches
Nut Length: Between 0.516 inches and 0.546 inches
Nut Style: Blind rivet w/smooth round shank
Shank End Type: Open
Specification Data: 80205-nas1329 professional/industrial association standard
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Head Diameter: Between 0.391 inches and 0.421 inches
