NAS1330C06K106 Plain Blind Rivet Nut
NAS1330C06K106 Plain Blind Rivet Nut (2)
NAS1330C06K106 Plain Blind Rivet Nut (3)
NAS1330C06K106 Plain Blind Rivet Nut
NAS1330C06K106 Plain Blind Rivet Nut (2)
NAS1330C06K106 Plain Blind Rivet Nut (3)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1330C06K106 Plain Blind Rivet Nut

Product Series
NAS
ECCN
EAR99
Schedule
7318.16.0085
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flat countersunk reverse keyed
Material
Steel comp 430
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3b
Thread Series
Unc (coarse thread)
Thread Size
0.138 inches
Err Default
+0.065 to 0.106 inches
Head Countersink Angle
Between 99.0 degrees and 101.0 degrees
Head Height
0.063 inches
Key Length
0.063 inches
Material Specification
66 federal standard single material response
Nut Diameter
Between 0.185 inches and 0.189 inches
Nut Length
Between 0.485 inches and 0.515 inches
Nut Style
Blind rivet w/smooth round shank
Shank End Type
Open
Thread Direction
Right-hand
Thread Qty Per Inch (tpi)
32
Head Diameter
0.323 inches
