NAS1330C08-106 Blind Rivet

NAS1330C08-106 Blind Rivet (2)

NAS1330C08-106 Blind Rivet (3)

NAS1330C08-106 Blind Rivet (4)

NAS1330C08-106 Blind Rivet (5)

NAS1330C08-106 Blind Rivet (6)

NAS1330C08-106 Blind Rivet (7)

NAS1330C08-106 Blind Rivet (8)

NAS1330C08-106 Blind Rivet (9)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1330C08-106 Blind Rivet

Product Series: NAS
ECCN: EAR99
Schedule: 7616.10.3000

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Head Style

Flat countersunk

Material

Steel comp 430

Surface Treatment

Qq-p-35 federal specification single treatment response

Thread Class

3b

Thread Series

Unc (coarse thread)

Thread Size

0.164 inches

Err Default: +0.065 to 0.106 inches
Head Countersink Angle: Between 99 degrees and 101 degrees
Nut Diameter: Between 0.217 inches and 0.221 inches
Nut Length: Between 0.485 inches and 0.515 inches
Nut Style: Blind rivet w/smooth round shank
Shank End Type: Open
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 32
Head Diameter: 0.355 inches
