NAS1351-08-8 Socket Head Cap Screw
NAS1351-08-8 Socket Head Cap Screw (2)
NAS1351-08-8 Socket Head Cap Screw (3)
NAS1351-08-8 Socket Head Cap Screw (4)
NAS1351-08-8 Socket Head Cap Screw (5)
NAS1351-08-8 Socket Head Cap Screw (6)
NAS1351-08-8 Socket Head Cap Screw
NAS1351-08-8 Socket Head Cap Screw (2)
NAS1351-08-8 Socket Head Cap Screw (3)
NAS1351-08-8 Socket Head Cap Screw (4)
NAS1351-08-8 Socket Head Cap Screw (5)
NAS1351-08-8 Socket Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1351-08-8 Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flat chamfer
Material
Steel
Surface Treatment
Cl1 military specification single treatment response mil-c-13924
Thread Class
3a
Fastener Length
Between 0.470 inches and 0.500 inches
Hardness Rating
38.0 rockwell c and 45.0 rockwell c
Head Height
Between 0.159 inches and 0.164 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
180000 pounds per square inch
Minimum Yield Strength
155000 pounds per square inch
Special Features
Finish color black
Specification Data
80205-nas1351 professional/industrial association standard
Thread Diameter
0.164 inches
Thread Direction
Right-hand
Thread Length
Between 0.414 inches and 0.500 inches
Thread Qty Per Inch (tpi)
36
Thread Series Designator
Unrf
Width Across Flats
Between 0.140 inches and 0.142 inches
Head Diameter
Between 0.262 inches and 0.270 inches
