NAS1351-3-32P Socket Head Cap Screw
NAS1351-3-32P Socket Head Cap Screw (2)
NAS1351-3-32P Socket Head Cap Screw (3)
NAS1351-3-32P Socket Head Cap Screw (4)
NAS1351-3-32P Socket Head Cap Screw (5)
NAS1351-3-32P Socket Head Cap Screw
NAS1351-3-32P Socket Head Cap Screw (2)
NAS1351-3-32P Socket Head Cap Screw (3)
NAS1351-3-32P Socket Head Cap Screw (4)
NAS1351-3-32P Socket Head Cap Screw (5)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1351-3-32P Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $3.68
Units per Pack 10
Price per Pack $36.80
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:
Total Packs 1
Total Price $36.80
Add item to quote
Head Style
Flat chamfer
Material
Steel
Surface Treatment
Type 2 cl 3 federal specification single treatment response qq-p-416
Thread Class
3a
Fastener Length
Between 1.960 inches and 2.000 inches
Hardness Rating
36.0 rockwell c and 45.0 rockwell c
Head Height
Between 0.185 inches and 0.190 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
160000 pounds per square inch
Minimum Yield Strength
130000 pounds per square inch
Nondefinitive Specification/std Data
6 type
Thread Diameter
0.190 inches
Thread Direction
Right-hand
Thread Length
Between 1.085 inches and 1.333 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unf (fine thread)
Width Across Flats
Between 0.156 inches and 0.158 inches
Head Diameter
Between 0.303 inches and 0.312 inches
