NAS1351-4-12P Socket Head Cap Screw
NAS1351-4-12P Socket Head Cap Screw (2)
NAS1351-4-12P Socket Head Cap Screw (3)
NAS1351-4-12P Socket Head Cap Screw (4)
NAS1351-4-12P Socket Head Cap Screw
NAS1351-4-12P Socket Head Cap Screw (2)
NAS1351-4-12P Socket Head Cap Screw (3)
NAS1351-4-12P Socket Head Cap Screw (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1351-4-12P Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $1.66
Units per Pack 25
Price per Pack $41.50
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:
Total Packs 1
Total Price $41.50
Add item to quote
Head Style
Flat chamfer
Material
Steel
Surface Treatment
Cl 2 federal specification single treatment response type 2 ams-qq-p-416
Thread Class
3a
Fastener Length
Between 0.734 inches and 0.766 inches
Hardness Rating
38.0 rockwell c and 45.0 rockwell c
Head Height
Between 0.244 inches and 0.250 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
170000 pounds per square inch
Minimum Yield Strength
150000 pounds per square inch
Specification Data
80205-nas1351 professional/industrial association standard
Thread Diameter
0.250 inches
Thread Direction
Right-hand
Thread Length
Between 0.663 inches and 0.766 inches
Thread Qty Per Inch (tpi)
28
Thread Series Designator
Unrf
Width Across Flats
Between 0.187 inches and 0.190 inches
Head Diameter
Between 0.365 inches and 0.375 inches
