NAS1351-5-8P Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flat chamfer
Material
Steel
Surface Treatment
Cl 2 federal specification single treatment response type 2 qq-p-416
Thread Class
3a
Fastener Length
Between 0.470 inches and 0.500 inches
Hardness Rating
38.0 rockwell c and 45.0 rockwell c
Head Height
Between 0.306 inches and 0.312 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
170000 pounds per square inch
Minimum Yield Strength
150000 pounds per square inch
Specification Data
80205-nas1351 professional/industrial association standard
Thread Diameter
0.312 inches
Thread Direction
Right-hand
Thread Length
Between 0.387 inches and 0.500 inches
Thread Qty Per Inch (tpi)
24
Thread Series Designator
Unrf
Width Across Flats
Between 0.250 inches and 0.253 inches
Head Diameter
Between 0.457 inches and 0.469 inches
