NAS1351-6-24P Socket Head Cap Screw
NAS1351-6-24P Socket Head Cap Screw (2)
NAS1351-6-24P Socket Head Cap Screw (3)
NAS1351-6-24P Socket Head Cap Screw (4)
NAS1351-6-24P Socket Head Cap Screw (5)
NAS1351-6-24P Socket Head Cap Screw (6)
NAS1351-6-24P Socket Head Cap Screw
NAS1351-6-24P Socket Head Cap Screw (2)
NAS1351-6-24P Socket Head Cap Screw (3)
NAS1351-6-24P Socket Head Cap Screw (4)
NAS1351-6-24P Socket Head Cap Screw (5)
NAS1351-6-24P Socket Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1351-6-24P Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.9000
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flat chamfer
Material
Steel
Surface Treatment
Class 2 federal specification all treatment responses type 2 qq-p-416
Thread Class
3a
Fastener Length
Between 1.46 inches and 1.50 inches
Hardness Rating
38.0 rockwell and 45.0 rockwell
Head Height
Between 0.365 inches and 0.368 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
170000 pounds per square inch
Minimum Yield Strength
150000 pounds per square inch
Specification Data
80205-nas1351 professional/industrial association standard
Thread Diameter
0.375 inches
Thread Direction
Right-hand
Thread Length
1.250 inches
Thread Qty Per Inch (tpi)
24
Thread Series Designator
Unrf
Width Across Flats
Between 0.312 inches and 0.316 inches
Head Diameter
Between 0.55 inches and 0.552 inches
