NAS1352-04H10P Socket Head Cap Screw

Product Series: NAS
ECCN: EAR99
Schedule: 7318.15.2091

Price per Unit $3.68

Units per Pack 10

Price per Pack $36.80

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $36.80

Add item to quote

Head Style

Flat chamfer

Material

Steel

Surface Treatment

Qq-p-416 type 2 cl 2 federal specification single treatment response

Thread Class

Fastener Length: Between 0.595 inches and 0.625 inches
Hardness Rating: 38.0 rockwell c and 45.0 rockwell c
Head Height: Between 0.108 inches and 0.112 inches
Hole Configuration Style: Round internal hexagon
Hole Quantity: 2
Hole Type: Drilled
Internal Drive Style: Hexagon
Min. Tensile Strength (psi): 180000 pounds per square inch
Minimum Yield Strength: 155000 pounds per square inch
Specification Data: 80205-nas1352 professional/industrial association standard
Thread Diameter: 0.112 inches
Thread Direction: Right-hand
Thread Length: Between 0.545 inches and 0.625 inches
Thread Qty Per Inch (tpi): 40
Thread Series Designator: Unrc
Width Across Flats: Between 0.0937 inches and 0.0952 inches
Head Diameter: Between 0.176 inches and 0.183 inches
Hole Diameter: Between 0.033 inches and 0.039 inches
