NAS1352-08-10P Socket Head Cap Screw
NAS1352-08-10P Socket Head Cap Screw (2)
NAS1352-08-10P Socket Head Cap Screw (3)
NAS1352-08-10P Socket Head Cap Screw (4)
NAS1352-08-10P Socket Head Cap Screw (5)
NAS1352-08-10P Socket Head Cap Screw (6)
NAS1352-08-10P Socket Head Cap Screw
NAS1352-08-10P Socket Head Cap Screw (2)
NAS1352-08-10P Socket Head Cap Screw (3)
NAS1352-08-10P Socket Head Cap Screw (4)
NAS1352-08-10P Socket Head Cap Screw (5)
NAS1352-08-10P Socket Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1352-08-10P Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $1.01
Units per Pack 50
Price per Pack $50.50
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 50

Total Unit Quantity:
Total Packs 1
Total Price $50.50
Add item to quote
Head Style
Flat chamfer
Material
Steel
Surface Treatment
Cl3 federal specification single treatment response ty2 qq-p-416
Thread Class
3a
Fastener Length
Between 0.595 inches and 0.625 inches
Hardness Rating
38.0 rockwell c and 45.0 rockwell c
Head Height
Between 0.159 inches and 0.164 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
180000 pounds per square inch
Minimum Yield Strength
130000 pounds per square inch
Nondefinitive Specification/std Data
6 type
Specification Data
80205-nas1352 professional/industrial association standard
Thread Diameter
0.164 inches
Thread Direction
Right-hand
Thread Length
Between 0.533 inches and 0.625 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unrc
Width Across Flats
Between 0.141 inches and 0.143 inches
Head Diameter
Between 0.262 inches and 0.270 inches
