NAS1352C01-6 Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Flat chamfer
Material
Steel comp 3130
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3a
Fastener Length
Between 0.359 inches and 0.391 inches
Hardness Rating
80.0 rockwell b
Head Height
Between 0.070 inches and 0.073 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
80000 pounds per square inch
Minimum Yield Strength
30000 pounds per square inch
Specification Data
80205-nas1352 professional/industrial association standard
Thread Diameter
0.073 inches
Thread Direction
Right-hand
Thread Length
0.328 inches
Thread Qty Per Inch (tpi)
64
Thread Series Designator
Unc (coarse thread)
Width Across Flats
Between 0.062 inches and 0.063 inches
Head Diameter
Between 0.112 inches and 0.118 inches
