NAS1352C06LL14 Socket Head Cap Screw
NAS1352C06LL14 Socket Head Cap Screw (2)
NAS1352C06LL14 Socket Head Cap Screw (3)
NAS1352C06LL14 Socket Head Cap Screw (4)
NAS1352C06LL14 Socket Head Cap Screw (5)
NAS1352C06LL14 Socket Head Cap Screw (6)
NAS1352C06LL14 Socket Head Cap Screw
NAS1352C06LL14 Socket Head Cap Screw (2)
NAS1352C06LL14 Socket Head Cap Screw (3)
NAS1352C06LL14 Socket Head Cap Screw (4)
NAS1352C06LL14 Socket Head Cap Screw (5)
NAS1352C06LL14 Socket Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1352C06LL14 Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.9000
Price per Unit $2.84
Units per Pack 10
Price per Pack $28.40
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:
Total Packs 1
Total Price $28.40
Add item to quote
Head Style
Flat chamfer
Material
Steel comp 302 or steel comp 304 or steel comp 305 or steel comp 316 or steel comp 384 or steel comp xm-7
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3a
Fastener Length
Between 0.845 inches and 0.875 inches
Hardness Rating
80.0 rockwell b
Head Height
Between 0.134 inches and 0.138 inches
Internal Drive Style
Hexagon
Locking Feature
Strip threads
Min. Tensile Strength (psi)
80000 pounds per square inch
Minimum Yield Strength
30000 pounds per square inch
Specification Data
80205-nas1352 professional/industrial association standard
Surface Finish
63.0 microinches bearing surface of head
Thread Diameter
0.138 inches
Thread Direction
Right-hand
Thread Length
Between 0.783 inches and 0.875 inches
Thread Qty Per Inch (tpi)
32
Thread Series Designator
Unrc
Width Across Flats
Between 0.1094 inches and 0.1111 inches
Head Diameter
Between 0.218 inches and 0.226 inches
