NAS1352C5-12 Socket Head Cap Screw
NAS1352C5-12 Socket Head Cap Screw (2)
NAS1352C5-12 Socket Head Cap Screw (3)
NAS1352C5-12 Socket Head Cap Screw (4)
NAS1352C5-12 Socket Head Cap Screw (5)
NAS1352C5-12 Socket Head Cap Screw (6)
NAS1352C5-12 Socket Head Cap Screw
NAS1352C5-12 Socket Head Cap Screw (2)
NAS1352C5-12 Socket Head Cap Screw (3)
NAS1352C5-12 Socket Head Cap Screw (4)
NAS1352C5-12 Socket Head Cap Screw (5)
NAS1352C5-12 Socket Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1352C5-12 Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $5.89
Units per Pack 10
Price per Pack $58.90
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:
Total Packs 1
Total Price $58.90
Add item to quote
Head Style
Flat chamfer
Material
Steel comp 302 or steel comp 304 or steel comp 305 or steel comp 316 or steel comp 384
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
3a
End Application
3990-01-442-1939 bap (bridge adapter pallet); hemtt family (heavy expanded mobility tactical trucks)
Fastener Length
Between 0.720 inches and 0.750 inches
Head Height
Between 0.306 inches and 0.312 inches
Internal Drive Style
Hexagon
Min. Tensile Strength (psi)
160000 pounds per square inch
Nondefinitive Specification/std Data
1 type and 49 style
Specification Data
80205-nas1352 professional/industrial association standard
Thread Diameter
0.312 inches
Thread Direction
Right-hand
Thread Length
Between 0.609 inches and 0.750 inches
Thread Qty Per Inch (tpi)
18
Thread Series Designator
Unrc
Width Across Flats
Between 0.250 inches and 0.253 inches
Head Diameter
Between 0.457 inches and 0.469 inches
