NAS1354DS7S15D Quick Release Pin

Product Series: NAS
ECCN: EAR99
Schedule: 7318.24.0000

Price per Unit $129.59

Units per Pack 1

Price per Pack $129.59

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 1

Total Unit Quantity:

Total Packs 1

Total Price $129.59

Add item to quote

Material

Steel comp 4130 spindle

Surface Treatment

Cl 2 federal specification single treatment response spindle type 2 qq-p-416

Actuation Method: Push button
Actuation Type: Pull and push
Detent Quantity: 2
Detent To Tapered End Distance: 0.410 inches
Features: Drive out feature
Features Provided: Drive out feature
Grip Length: Between 1.500 inches and 1.520 inches
Hardness Rating: 36.0 rockwell c shank and 40.0 rockwell c shank
Material Specification: Mil-s-6758 military specification 1st material response shank or mil-t-6736 military specification 1st material response shank or mil-t-6735 military specification 2nd material response shank
Pin Attachment Type: Hook or ring
Ring Handle Diameter: 1.220 inches
Shank Diameter: Between 0.2470 inches and 0.2495 inches
Shoulder To Head End Distance: 1.730 inches
Specification Data: 80205-nas1354 professional/industrial association standard
Style Designator: Ring handle
Head Diameter: 0.750 inches
