NAS1395C08 Screw Thread Insert

Product Series: NAS
ECCN: EAR99
Schedule: 7318.16.0085

Price per Unit $4.16

Units per Pack 10

Price per Pack $41.60

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $41.60

Add item to quote

Material

Steel comp 303

Thread Class

3b

Thread Size

0.164 inches

Full Internal Thread Length: 0.270 inches
Insert Size: 0.312-18 unc (coarse thread) 2a
Internal Thread Relief Depth: 0.040 inches
Length: 0.310 inches
Material Specification: Cond b military specification single material response mil-s-7720
Style Designator: Keylock
Thread Qty Per Inch (tpi): 32
Thread Series Designator: Unc (coarse thread)
