NAS1423C6LH Nut

Product Series: NAS
ECCN: EAR99
Schedule: 7318.16.0085

Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Material

Stainless Steel

Thread Class

3b

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.375 inches

Bearing Surface Type: Chamfered
Inside Width Across Flats: Between 0.553 inches and 0.565 inches
Nut Height: 0.125 inches
Nut Style: Hexagon
Part Name Assigned By Controlling Agency: thin drilled jam hexagon plain nut
Special Features: Material cres a-286 (uns s66286); external edges chamfered at 30 deg; heat treat 15.000 psi min ts; width across points 0.628
Thread Direction: Left-hand
Thread Qty Per Inch (tpi): 24
Width Across Flats: Between 0.553 inches and 0.565 inches
