NAS1635-02-20 Socket Head Cap Screw
NAS1635-02-20 Socket Head Cap Screw (2)
NAS1635-02-20 Socket Head Cap Screw (3)
NAS1635-02-20 Socket Head Cap Screw (4)
NAS1635-02-20 Socket Head Cap Screw (5)
NAS1635-02-20 Socket Head Cap Screw (6)
NAS1635-02-20 Socket Head Cap Screw
NAS1635-02-20 Socket Head Cap Screw (2)
NAS1635-02-20 Socket Head Cap Screw (3)
NAS1635-02-20 Socket Head Cap Screw (4)
NAS1635-02-20 Socket Head Cap Screw (5)
NAS1635-02-20 Socket Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1635-02-20 Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Head Style
Pan
Thread Class
2a
Fastener Length
1.250 inches
Head Height
Between 0.053 inches and 0.062 inches
Internal Drive Style
Cross recess type 1
Screw Material
Steel comp 303
Screw Material Specification
Mil-s-7720 military specification single material response
Screw Surface Treatment
Passivate
Thread Diameter
0.086 inches
Thread Direction
Right-hand
Thread Length
1.250 inches
Thread Qty Per Inch (tpi)
56
Thread Series Designator
Unc (coarse thread)
Head Diameter
Between 0.155 inches and 0.167 inches
