Home » NAS1635-4-12 Socket Head Cap Screw
NAS1635-4-12 Socket Head Cap Screw
NAS1635-4-12 Socket Head Cap Screw (2)
NAS1635-4-12 Socket Head Cap Screw (3)
NAS1635-4-12 Socket Head Cap Screw (4)
NAS1635-4-12 Socket Head Cap Screw (5)
NAS1635-4-12 Socket Head Cap Screw (6)
NAS1635-4-12 Socket Head Cap Screw
NAS1635-4-12 Socket Head Cap Screw (2)
NAS1635-4-12 Socket Head Cap Screw (3)
NAS1635-4-12 Socket Head Cap Screw (4)
NAS1635-4-12 Socket Head Cap Screw (5)
NAS1635-4-12 Socket Head Cap Screw (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1635-4-12 Socket Head Cap Screw

Product Series
NAS
ECCN
EAR99
Schedule
7318.15.2091
Price per Unit $1.39
Units per Pack 25
Price per Pack $34.75
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 25

Total Unit Quantity:
Total Packs 1
Total Price $34.75
Add item to quote
Head Style
Pan
Material
Stainless Steel
Surface Treatment
Qq-p-35 federal specification single treatment response
Thread Class
2a
Fastener Length
Between 0.72 inches and 0.75 inches
Head Height
Between 0.162 inches and 0.175 inches
Internal Drive Style
Cross recess type 1
Specification Data
80205-nas1635 professional/industrial association standard
Thread Diameter
0.25 inches
Thread Direction
Right-hand
Thread Length
Between 0.649 inches and 0.750 inches
Thread Qty Per Inch (tpi)
28
Thread Series Designator
Unf (fine thread)
Head Diameter
Between 0.473 inches and 0.492 inches
