NAS1715C22K Loop Clamp
NAS1715C22K Loop Clamp (2)
NAS1715C22K Loop Clamp (3)
NAS1715C22K Loop Clamp (4)
NAS1715C22K Loop Clamp
NAS1715C22K Loop Clamp (2)
NAS1715C22K Loop Clamp (3)
NAS1715C22K Loop Clamp (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1715C22K Loop Clamp

Product Series
NAS
ECCN
EAR99
Schedule
7616.10.9090
Price per Unit $41.58
Units per Pack 2
Price per Pack $83.16
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 2

Total Unit Quantity:
Total Packs 1
Total Price $83.16
Add item to quote
Material
Plastic cushion
Surface Treatment
Qq-p-35 federal specification single treatment response band
Center To Center Distance Between Loop And Mounting Hole
Between 1.162 inches and 1.192 inches
Cushioning Environmental Protection
Heat
Distance From Loop Center To Tongue End
Between 1.381 inches and 1.411 inches
Loop Inside Diameter
Between 1.360 inches and 1.390 inches
Material Specification
Comp ti 321 military specification 2nd material response band mil-s-5059 military specification 1st material response band or mil-s-6721
Material Thickness
0.051 inches
Overall Width
0.500 inches
Specification Data
80205-nas1715 professional/industrial association standard
Style Designator
Offset mount
Tongue Hole Type
unthreaded round
Diameter
0.204 inches
