NAS1833-4-500 Screw Thread Insert
NAS1833-4-500 Screw Thread Insert (2)
NAS1833-4-500 Screw Thread Insert (3)
NAS1833-4-500 Screw Thread Insert (4)
NAS1833-4-500 Screw Thread Insert (5)
NAS1833-4-500 Screw Thread Insert (6)
NAS1833-4-500 Screw Thread Insert
NAS1833-4-500 Screw Thread Insert (2)
NAS1833-4-500 Screw Thread Insert (3)
NAS1833-4-500 Screw Thread Insert (4)
NAS1833-4-500 Screw Thread Insert (5)
NAS1833-4-500 Screw Thread Insert (6)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS1833-4-500 Screw Thread Insert

Product Series
NAS
ECCN
EAR99
Schedule
7318.16.0085
Price per Unit $5.78
Units per Pack 10
Price per Pack $57.80
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:
Total Packs 1
Total Price $57.80
Add item to quote
Material
Steel
Overall Length
0.500 inches
Surface Treatment
Cl 2 federal specification single treatment response type 2 qq-p-416
Features
Potting hole or potting slot
Features Provided
Potting hole or potting slot
Flange Thickness
0.060 inches
Hole Type
Threaded
Insert Style
Protruding flange
Material Specification
66 assn standard all material responses
Specification Data
80205-na1833 professional/industrial association standard
Thread Size And Series/type Designator
0.250-28 unjf (fine thread with external controlled root radius)
Flange Diameter
Between 0.675 inches and 0.685 inches
