NAS1834-3-250 Screw Thread Insert

Product Series: NAS
ECCN: EAR99
Schedule: 7318.15.9000

Price per Unit $3.60

Units per Pack 10

Price per Pack $36.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $36.00

Add item to quote

Material

Steel

Overall Length

0.250 inches

Surface Treatment

Cl2 federal specification single treatment response ty2 qq-p-416

Features: Potting hole and potting slot
Features Provided: Potting hole and potting slot
Hole Type: Plain
Insert Style: Protruding flange
Material Accommodated Thickness: Between 0.561 inches and 0.566 inches
Material Specification: 66 federal standard single material response
Shoulder Diameter: 0.300 inches
Specification Data: 80205-nas1834 professional/industrial association standard
Flange Diameter: Between 0.550 inches and 0.560 inches
Hole Diameter: 0.196 inches
