NAS1921C04S03U Blind Rivet

Product Series: NAS
ECCN: EAR99
Schedule: 7616.10.3000

Price per Unit $6.07

Units per Pack 10

Price per Pack $60.70

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $60.70

Add item to quote

Head Style

Flush (flat) countersunk (included angle - less than 135 degrees w or w/o chamfer)

Material

Iron alloy 660 stem

Surface Treatment

Qq-p-35 federal specification single treatment response stem

Countersink Angle: Between 98.5 degrees and 101.5 degrees
Fastener Length: 0.323 inches
Grip Length: Between 0.126 inches and 0.187 inches
Head Major Diameter: Between 0.221 inches and 0.229 inches
Material Specification: Ams 5737 assn standard single material response sleeve
Shank Diameter: Between 0.124 inches and 0.128 inches
Shank Style: Self-plugging mechanically locked stem
