NAS577B4F Plain Hexagon Nut

Product Series: NAS
ECCN: EAR99
Schedule: 7318.16.0085

Price per Unit $61.15

Units per Pack 1

Price per Pack $61.15

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 1

Total Unit Quantity:

Total Packs 1

Total Price $61.15

Add item to quote

Material

Steel

Thread Class

3b

Thread Series

Unjf (fine thread with external controlled root radius)

Thread Size

0.250 inches

Barrel Height: Between 0.310 inches and 0.320 inches
Features: Floating nut
Features Provided: Floating nut
Locking Feature: Prevailing torque all metal design
Nut Diameter: Between 0.525 inches and 0.528 inches
Nut Height: 0.406 inches
Nut Length: 0.625 inches
Nut Style: Floating self-locking barrel
Tempurature Rating: 500.0 degrees fahrenheit
Thread Direction: Right-hand
Thread Qty Per Inch (tpi): 28
