NAS577B8A Self-locking Barrel Nut

NSN
5310-00-802-1268
Product Series
NAS
ECCN
EAR99
Schedule
7318.16.0085
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel
Thread Class
3b
Thread Series
Unf (fine thread)
Thread Size
0.500 inches
Barrel Height
0.540 inches
Locking Feature
Prevailing torque all metal design
Nut Diameter
Between 0.872 inches and 0.875 inches
Nut Height
0.703 inches
Nut Length
1.000 inches
Nut Style
Non-floating self-locking barrel
Tempurature Rating
550.0 degrees fahrenheit
Thread Direction
Right-hand
Thread Qty Per Inch (tpi)
20
