NAS6706U21 Shear Bolt

Product Series: NAS
ECCN: EAR99
Schedule: 7318.15.8085

Price per Unit $20.10

Units per Pack 2

Price per Pack $40.20

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 2

Total Unit Quantity:

Total Packs 1

Total Price $40.20

Add item to quote

Head Style

Dished hexagon

Material

Stainless Steel

Thread Class

3a

End Application: panavia aircraft c0890
Grip Diameter: Between 0.436 inches and 0.437 inches
Grip Length: Between 1.302 inches and 1.322 inches
Head Height: Between 0.188 inches and 0.203 inches
Thread Diameter: 0.375 inches
Thread Direction: Right-hand
Thread Length: 0.578 inches
Thread Qty Per Inch (tpi): 24
Thread Series Designator: Unjf (fine thread with external controlled root radius)
Width Between Flats: Between 0.554 inches and 0.564 inches
