NAS671-10 Plain Hexagon Nut
NAS671-10 Plain Hexagon Nut (2)
NAS671-10 Plain Hexagon Nut (3)
NAS671-10 Plain Hexagon Nut
NAS671-10 Plain Hexagon Nut (2)
NAS671-10 Plain Hexagon Nut (3)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS671-10 Plain Hexagon Nut

Product Series
NAS
ECCN
EAR99
Schedule
7318.16.0085
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Add to Quote

We are currently out of stock of this item. Click the button below to add this item to the quote and receive up to date pricing and availability by email.

Add to Quote
Material
Steel
Surface Treatment
Cl 2 federal specification single treatment response type 2 qq-p-416
Thread Class
3b
Thread Series
Unjf (fine thread with external controlled root radius)
Thread Size
0.190 inches
Bearing Surface Type
Chamfered or washer faced
Countersink Angle
110.0 degrees nut
Material Specification
66 federal standard single material response
Nut Height
Between 0.117 inches and 0.130 inches
Nut Style
Hexagon
Thread Direction
Right-hand
Thread Qty Per Inch (tpi)
32
Width Across Flats
Between 0.332 inches and 0.344 inches
