Home » NAS75-10-016 Sleeve Bushing
NAS75-10-016 Sleeve Bushing
NAS75-10-016 Sleeve Bushing (2)
NAS75-10-016 Sleeve Bushing (3)
NAS75-10-016 Sleeve Bushing (4)
NAS75-10-016 Sleeve Bushing
NAS75-10-016 Sleeve Bushing (2)
NAS75-10-016 Sleeve Bushing (3)
NAS75-10-016 Sleeve Bushing (4)

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

NAS75-10-016 Sleeve Bushing

Product Series
NAS
ECCN
EAR99
Schedule
7412.20.0000
Price per Unit $12.82
Units per Pack 5
Price per Pack $64.10
Manufacturer certifications are shipped with your order FREE of charge
Unit of Measure: EA

Quantity will be increased in increments of 5

Total Unit Quantity:
Total Packs 1
Total Price $64.10
Add item to quote
Material
Steel comp 4130 or steel comp 8630
Overall Length
Between 0.4950 inches and 0.5000 inches
Surface Treatment
Cl 3 federal specification single treatment response type 2 qq-p-416
Body Inside Diameter
Between 0.6250 inches and 0.6265 inches
Body Outside Diameter
Between 0.8132 inches and 0.8142 inches
Corner Shape
Square outside right corner
Material Specification
Mil-s-6758 military specification 1st material response or mil-s-6050 military specification 2nd material response
Special Features
Id and od to be parallel and concentric within 0.0030 tir
Specification Data
80205-nas75 professional/industrial association standard
Style Designator
no outside flanges plain solid
Surface Finish
125.0 microinches intermediate layer
