NAS76A3-020P Sleeve Bushing

Product Series: NAS
ECCN: EAR99
Schedule: 7412.20.0000

Price per Unit $6.45

Units per Pack 10

Price per Pack $64.50

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 10

Total Unit Quantity:

Total Packs 1

Total Price $64.50

Add item to quote

Material

Copper alloy 642 or copper alloy 630

Overall Length

Between 0.6200 inches and 0.6250 inches

Surface Treatment

Cl 2 federal specification single treatment response type 2 qq-p-416

Body Inside Diameter: Between 0.1900 inches and 0.1915 inches
Body Outside Diameter: Between 0.3131 inches and 0.3136 inches
Corner Shape: Square outside right corner
Material Specification: Astm b150 national specification single material response
Specification Data: 80205-nas76 professional/industrial association standard
Style Designator: no outside flanges plain solid
Surface Finish: 125.0 microinches intermediate layer
