NAS76A6-026 Sleeve Bushing

Product Series: NAS
ECCN: EAR99
Schedule: 8483.30.8090

Price per Unit $12.40

Units per Pack 5

Price per Pack $62.00

Manufacturer certifications are shipped with your order FREE of charge

Unit of Measure: EA

Quantity will be increased in increments of 5

Total Unit Quantity:

Total Packs 1

Total Price $62.00

Add item to quote

Material

Copper alloy 642

Overall Length

Between 0.8075 inches and 0.8125 inches

Body Inside Diameter: Between 0.375 inches and 0.3765 inches
Body Outside Diameter: Between 0.5006 inches and 0.5013 inches
Corner Shape: Chamfered inside left corner
Material Specification: Qq-c-465 federal specification single material response
Specification Data: 80205-nas76 professional/industrial association standard
Style Designator: no outside flanges plain solid
Surface Finish: 125 microinches intermediate layer
