NAS1352-08-10P

Socket Head Cap Screw

email this to someone
Description:

length: 5/8", thread: 8-32, cadmium plated alloy steel, NAS1352 series screw

* Manufacturer certifications are shipped with your order FREE of charge
NAS1352-08-10P NAS1352-08-10P NAS1352-08-10P NAS1352-08-10P NAS1352-08-10P NAS1352-08-10P
Add to Cart
Up to qty 1250 ships same day if ordered before 4pm EST
NAS1352-08-10P Price:
buy now
$0.80 Each
Quantity:
sold in increments of 50
* Sold in increments of 50
Add item to quote

NAS1352-08-10P Features and Specification

Thread Class:
3a
Thread Direction:
Right-hand
Thread Length:
0.533 inches minimum and 0.625 inches maximum
Fastener Length:
0.595 inches minimum and 0.625 inches maximum
Head Style:
Flat chamfer
Head Diameter:
0.262 inches minimum and 0.270 inches maximum
Head Height:
0.159 inches minimum and 0.164 inches maximum
Internal Drive Style:
Hexagon
Thread Diameter:
0.164 inches
Width Across Flats:
0.141 inches minimum and 0.143 inches maximum
Thready Qty Per Inch (tpi):
32
Min. Tensile Strength (psi):
180000 pounds per square inch
Hardness Rating:
38.0 rockwell c minimum overall and 45.0 rockwell c maximum overall
Minimum Yield Strength:
130000 pounds per square inch
Material:
Steel overall
Surface Treatment:
Cadmium overall and chromate overall
Surface Treatment Specification:
Qq-p-416,ty2,cl3 fed spec single treatment response overall
Thread Series Designator:
Unrc
Specification Data:
80205-nas1352 professional/industrial association standard
Nondefinitive Specification/std Data:
6 type

Additional Information

SKU / Model: NAS13520810P
Minimum Qty (MOQ): 50
NSN: 5305-00-493-6399
FSC: Screws / 5305
Schedule B: 7318.15.6080
ECCN: EAR99
National Motor Freight: 093486, Bolts,nuts Or Screws, Noi (sub 3)
Download PDF Version
NAS1352-08-10P_Military-Fasteners-com.pdf
