M39029/58-365

Electrical Contact

email this to someone

Description:

pin, size 12, fits series: mil-c-24308, mil-c-38999 ser i-iv, mil-c-55302/69, mil-c-83733, use insertion / removal tool m81969/14-04

* Manufacturer certifications are shipped with your order FREE of charge

Add to Cart Up to qty 600 ships same day if ordered before 4pm EST

M39029/58-365 Price:	buy now $1.66 Each
Quantity: Pre-packaged bag qty: 25 ea
* Sold in increments of 25

Add item to quote

M39029/58-365 Datasheet Features and Specification

Crimping Tool Identifying Number:

M22520/1-01

Iii Style Designator:

Pin contact

Material:

Copper alloy body and contact

Mounting Method:

Terminal

Overall Diameter:

Between 0.179 inches and 0.182 inches

Overall Length:

0.531 inches

Precious Material:

Gold

Precious Material And Location:

Body and contact surfaces gold

Precious Material And Weight:

Troy 0.005 gold grains

Specification Data:

81349-mil-c-39029/58 government specification

Surface Treatment:

Gold body and contact

Surface Treatment Specification:

Mil-g-45204 military specification single treatment response body and contact

Terminal Type And Quantity:

1 crimp end opposite contact

Test Data Document:

Etc.).

Quick Specs

Material

Copper

Additional Information

Alternate Part Numbers

M39029-58-365

SKU / Model:	M3902958365
NSN:	5999-01-123-7941
FSC:	Miscellaneous Electrical and Electronic Components / 5999
Product Series:	M39029/58
Pack Weight (Approx.)	0.000 lb
Minimum Qty (MOQ):	25
ECCN:	EAR99
National Motor Freight:	061300, Circuit Breaker / Switch Noi
Download PDF Version M39029/58-365_Military-Fasteners-com.pdf
