MS35769-26

Military Standard Gasket

email this to someone
Description:

inner diameter: 1-1/8", thickness 3/32", gasket

* Manufacturer certifications are shipped with your order FREE of charge
MS35769-26
MS35769-26
MS35769-26
Add to Quote We are currently out of stock of this item. Click the button below to add this item to a quote and receive up to date pricing and availability by email.

Add to Quote

MS35769-26 Datasheet Features and Specification

Cross Sectional Shape:
Metal with soft filler
Tempurature Rating:
500.0 deg fahrenheit
Outside Diameter:
1.359 inches minimum and 1.375 inches maximum
Aperture Diameter:
1.125 inches minimum and 1.141 inches maximum
Cross-sectional Thickness:
0.078 inches minimum and 0.109 inches maximum
Criticality Code Justification:
Matt
Maximum Pressure Rating:
200.0 pounds per square inch
Environmental Attribute Code:
Asbestos alternative products
Special Features:
As differentiated by filler of non-asbestos material
Material:
Copper case
Material:
Fiber nonasbestos core and asphalt core and rubber butadiene-acrylonitrile class nbr core
Material Specification:
Hh-g-101 fed spec single material response case
Material Specification:
Hh-g-101,type 3 fed spec single material response core
Style Designator:
Circular

Additional Information

SKU / Model: MS3576926
NSN: 5330-01-352-3132
FSC: Packing and Gasket Materials / 5330
Product Series: MS35769
Pack Weight (Approx.) 0.000 lb
Minimum Qty (MOQ): 25
ECCN: EAR99
National Motor Freight: 194120, Washers / Gaskets / Pckg Dvcs Noi
Download PDF Version
MS35769-26_Military-Fasteners-com.pdf
