MS9385-06

Military Standard Ring O

email this to someone
Description:

outer diameter: 3/8", preformed packing, MS9385 series oring

* Manufacturer certifications are shipped with your order FREE of charge
MS9385-06
MS9385-06
MS9385-06
MS9385-06
Add to Cart Up to qty 75 ships same day if ordered before 4pm EST
MS9385-06 Price:
buy now
$1.04 Each
Quantity:
Pre-packaged bag qty: 25 ea
* Sold in increments of 25
Add item to quote

MS9385-06 Datasheet Features and Specification

Outside Diameter:
0.624 inches nominal
Tempurature Rating:
-85.0 deg fahrenheit and 500.0 deg fahrenheit
Cross-sectional Height:
0.075 inches minimum and 0.081 inches maximum
Center Hole Diameter:
0.463 inches minimum and 0.473 inches maximum
Elongation Percentage:
125 maximum
Hardness Rating:
75.0 shore durometer a nominal
Material:
Rubber silicone class q

Additional Information

SKU / Model: MS938506
NSN: 5331-00-132-6971
FSC: Rings O / 5331
Product Series: MS9385
Pack Weight (Approx.) 0.100 lb
Minimum Qty (MOQ): 25
ECCN: EAR99
National Motor Freight: 194120, Washers / Gaskets / Pckg Dvcs Noi
Download PDF Version
MS9385-06_Military-Fasteners-com.pdf
Worldwide Shipping In stock and ready to ship!
