MS51021-10

Military Standard Setscrew

email this to someone
Description:

Length: 0.188", stainless steel, MS51021 series screw

* Manufacturer certifications are shipped with your order FREE of charge
MS51021-10
MS51021-10
MS51021-10
MS51021-10
MS51021-10
MS51021-10
MS51021-10
MS51021-10
Add to Cart Up to qty 1600 ships same day if ordered before 4pm EST
MS51021-10 Price:
buy now
$1.46 Each
Quantity:
Pre-packaged bag qty: 25 ea
* Sold in increments of 25
Add item to quote

MS51021-10 Datasheet Features and Specification

Thread Class:
3a
Thread Direction:
Right-hand
Thread Length:
0.188 inches minimum
Fastener Length:
0.188 inches nominal
Head Style:
Headless (setscrew)
Point Style:
Cup
Internal Drive Style:
Hexagon
Thread Diameter:
0.112 inches
Width Across Flats:
0.050 inches minimum and 0.051 inches maximum
Thready Qty Per Inch (tpi):
40
Material:
Steel comp 303 overall or steel comp 302 overall or steel comp 304 overall
Surface Treatment:
Passivate overall
Thread Series Designator:
Unc
Quick Specs
Thread Size 4
Thread Qty 40
Material Steel
Length 3/16

Additional Information

SKU / Model: MS5102110
NSN: 5305-00-655-9246
FSC: Screws / 5305
Product Series: MS51021
Pack Weight (Approx.) 0.000 lb
Minimum Qty (MOQ): 25
Schedule B: 7318.15.6080
ECCN: EARA99
National Motor Freight: 093486, Bolts,nuts Or Screws, Noi (sub 3)
Download PDF Version
MS51021-10_Military-Fasteners-com.pdf
